Ohlins RXF36 m.3 Suspension Fork - 29", 150mm, 15mm x 110mm, 44mm Offset, TTX18 Damper, Dual Adjust Air Spring, Gloss Black
MPN: FGMTB 3615 2411 · UPC: 840153642883
The RXF36 m.3 features an all-new chassis built around the race-proven TTX18 damper cartridge. This lightweight and highly progressive fork is fully optimized for demanding, next-level trail riding performance. The Ohlins race-winning TTX18 damping technology from the DH38 Race Fork has been adapted to deliver its renowned top-tier traction and control on the most demanding trails. The updated settings and reduced chassis friction offers improved sensitivity for greater traction and comfort to conquer any trail~With the new chassis, the fork delivers ultra-sensitive tracking over small bumps while maintaining Ohlins' signature precise steering and predictable handling—no matter how long or hard it's pushed.
- ✓ RXF36 m.3 features increased internal bushing overlap and an optimized configuration for 29” wheels
- ✓ Race-proven adjustment range is specifically designed for tough trails and provides 16 clicks of low-speed compression, 3 clicks of high-speed compression, and 16 clicks of rebound adjustment
- ✓ Features Ohlins' floating axle design for minimal friction and weighs 2050 g (with bolts and axle)
- ✓ The retuned, twin piston, three chamber air-spring system allows you to completely dial-in the level of progression—from the initial movement, right through to the bottom out
- ✓ Air spring is cartridge-based, allowing for easy swaps between coil and air if desired (coil cartridge sold separately)
- ✓ New surface treatment on the 36mm stanchions lowers the friction, boosts small bump sensitivity and overall ride smoothness
- ✓ Updated lowers feature a gloss black finish and bold new graphics, ensuring riders can feel and see the next level of performance every time they hit the trail or park
- ✓ 15mm x 110mm boost floating thru-axle axle design to minimize friction
- ✓ eMTB approved
| Steerer Type | Tapered |
| Lockout Switch | Crown |
| Brake Type | Post Mount 180 |
| Negative Spring | Air |
| Travel (mm) | 150 |
| Offset | 44 |
| Axle to Crown Length | 563 |
| Front Axle | 15mm Thru x 110mm |
| Maximum Tire Width | 66 |
| S.H.I.S. Stem Clamp Diameter | 28.6 |
| Color | Gloss Black |
| Crown Race | 40 |
| Weight | 2050 |
| Wheel Size | 29" |
| External Adjustments | Rebound Damping |
| Defined Color | Black |
| Positive Spring | Air |
| keyword search | Suggested Order |
| Stanchion Diameter | 36 |
