Ohlins RXF34 m.2 Suspension Fork - 29", 130mm, 15mm x 110mm, 44mm Offset, OTX18 Damper, Air Spring, Black
MPN: FGMTB 3413 2230 · UPC: 840153623035
Designed for riders who cover lots of ground—FAST. The new fork replaces the original RXF34, and offers a short-travel 120-130mm setup optimized for lightweight 29er trail bikes. Weighing in at just 1698g, the fork boasts a brand new air spring and damper adapted for the demands of the emerging riding style, while still carrying all the hallmarks of Öhlins’ race-proven performance suspension seen from its long-travel, single-crown cousins—the RXF36 m.2 & RXF38 m.2. The RXF34 m.2 uses the newly designed OTX18 damper which purpose-built for lightweight trail bikes. The new damper is paired with a robust yet lightweight air spring that features a positive and self-adjusting negative chamber. With a flex pattern tailored for lightweight trail riding, the RXF34 m.2’s super-stiff chassis delivers point-and-shoot precision steering.
- ✓ OTX18 damper shares several key components with its bigger TTX18 brother, but weighs 27% less and is optimized for faster and more fluid trail riding, striking the optimal balance between traction, control, weight and stiffness
- ✓ Trail-optimized OTX18 damper offers impressive adjustability for fine-tuning, with fifteen clicks of low-speed compression and rebound adjustment alongside three for tweaks to high-speed compression
- ✓ Lightweight air spring features a positive chamber that allows riders to tune the spring curve according to their needs using Öhlins’ easy-to-use volume spacer system
- ✓ Negative chamber of the lightweight air spring has been designed for fast trail riding and provides a plush initial feel and superb small bump sensitivity, while the spring’s surface and seals also minimize friction and breakaway force to enhance the fork’s smooth ride feel
- ✓ Race-proven chassis design has been achieved via a closed-end outer tube design to increase stiffness, impact resistance and the volume of the lower legs to give the rider more power to fine-tune performance to their liking for greater confidence and control
- ✓ 15mm x 110mm boost floating thru-axle axle design to minimize friction
- ✓ eMTB approved
| Steerer Type | Tapered |
| Lockout Switch | Crown |
| Brake Type | Post Mount 180 |
| Negative Spring | Air |
| Travel (mm) | 130 |
| Offset | 44 |
| Axle to Crown Length | 541 |
| Front Axle | 15mm Thru x 110mm |
| Maximum Tire Width | 66 |
| S.H.I.S. Stem Clamp Diameter | 28.6 |
| Color | Black |
| Crown Race | 40 |
| Wheel Size | 29" |
| External Adjustments | Rebound Damping |
| Defined Color | Black |
| Positive Spring | Air |
| Stanchion Diameter | 34 |
