Ohlins

Ohlins Air Spring Tube Rebuild Kit - 170mm, Compatible w/all Ohlins Forks with 3-Chamber Air Spring Cartridge

MPN: 18976-06 · UPC: 840153640407

$55.00

Out of Stock — Call for Availability

Select Option: — Choose —

🏪 Free pickup: 26 Essex St (Rear), Andover MA · 978-270-4895

🔒 Secure Checkout

💳 Visa · MC · Amex · Apple Pay

📦 Free Ship $99+

🚚 Local Delivery $20

The Ohlins air spring tube rebuild kit for their forks that have a 3-chamber air spring cartridge provides a more economical way to change travel/stroke.

✓ Provides a more economical way to change stroke however, requires 26mm ⌀ shaft clamps, Loctite 577, a cassette lockring tool, and a good set of Knipex to hold the sealhead while unthreading (all required tools and supplies sold separately)
✓ These air tubes are universal within the Ohlins 3-chamber air spring system, so be sure to not exceed the travel maximums set by the bushing overlap on each fork (e.g., don't put a 180mm air tube into an RXF36 m.3)
✓ Includes a 170 mm air tube and 2 sealing o-rings
✓ Relatively easy and economical travel change
✓ Interchangeable air tubes works with all Ohlins 3-chamber forks
✓ Intended for RXF fork series: RXF 36 m.2 (all) maximum travel: 180mm / RXF36 m.3 (29” wheel version) maximum travel: 160mm / RXF36 m.3 (27.5” wheel version) maximum travel: 170mm /170mm / RXF38 m.1, m.2, m.3 maximum travel: 180mm
