DVO

DVO Diamond D1 Suspension Fork - 27.5", 170mm Travel, 37mm Offset, 15 x 110mm, Black

MPN: 1619131-X2 · UPC: 811551023918

$749.00

Out of Stock — Call for Availability

💳 Pay as low as $749/mo with Affirm. Prequalify now

Select Option: — Choose —

🏪 Free pickup: 26 Essex St (Rear), Andover MA · 978-270-4895

🔒 Secure Checkout

💳 Visa · MC · Amex · Apple Pay

📦 Free Ship $99+

🚚 Local Delivery $20

An enduro/trail fork that offers quick, dynamic tunability of the negative air spring and high/low speed compression without dropping the fork from the bike or losing any oil. Adjustable 130 - 160mm travel. Boost options are 140 - 160mm (29er) or 150 - 170mm (27.5"")

✓ 35mm Tapered alloy stanchions
✓ Fender snaps in place with one bolt
✓ Off The Top (OTT) allows external preload adjustment of the negative spring, for small bump compliance without sacrificing mid-stroke feel
✓ Top Loader Compression circuit can be removed, reconfigured and reinstalled without removing the fork from the bike or the wheel from the fork
✓ A compressed, closed damping cartridge bladder eliminates breakaway forces and offers small bump sensitivity
✓ Externally adjustable rebound, high speed and low speed damping

Steerer Type	Tapered
Defined Color	Black
Positive Spring	Air
Wheel Size	27.5"
Offset	37
External Adjustments	Rebound Damping
Color	Black
Lockout Switch	Crown
Negative Spring	Air
Travel (mm)	170
S.H.I.S. Stem Clamp Diameter	28.6
Steerer Tube Length (mm)	255
Weight	2100
Stanchion Diameter	35
Axle to Crown Length	565
Crown Race	40
Front Axle	15mm Thru x 110mm
Brake Type	Post Mount 160
