Cane Creek Helm MKII Air 29 Suspension Fork - 29", 160 mm, 15 x 110 mm, 44 mm Offset, Gloss Black

MPN: BAG0685 · UPC: 840226098906

$1099.99

Out of Stock — Call for Availability

💳 Pay as low as $1100/mo with Affirm. Prequalify now

Select Option: — Choose —

🏪 Free pickup: 26 Essex St (Rear), Andover MA · 978-270-4895

🔒 Secure Checkout

💳 Visa · MC · Amex · Apple Pay

📦 Free Ship $99+

🚚 Local Delivery $20

The Cane Creek Helm MKII Air Suspension Fork features an upgraded damper design for increased support and control and a redesigned air spring that allows for increased air volume for better traction and suppleness.

✓ Compression and midvalve circuit offer increased support and control
✓ SKF oil seal head cartridge and wiper seals are low friction
✓ The redesigned air spring offers increased air volume for better traction and suppleness
✓ The threadless air seal head allows for easier travel change
✓ Damping features include: high speed compression, low speed compression, and low speed rebound
✓ Adjustment options include: high speed compression (10 positions), low speed compression (17 positions), Low speed rebound (10 positions), independent positive air spring, independent negative air spring, and an indexed travel system (8 positions)
✓ Double-Air spring system: high volume positive and negative air springs
✓ "D-Loc" 15mm bolt-on thru axle
✓ Max rotor size: 203
✓ 1.5" tapered steerer tube diameter

Steerer Type	Tapered
Brake Type	Post Mount 180
Negative Spring	Air
Travel (mm)	160
Offset	44
Axle to Crown Length	573
Front Axle	15mm Thru x 110mm
Maximum Tire Width	65
S.H.I.S. Stem Clamp Diameter	28.6
Color	Gloss Black
Crown Race	40
Weight	2080
Wheel Size	29"
External Adjustments	Rebound Damping
Defined Color	Black
Positive Spring	Air
Stanchion Diameter	35
Steerer Tube Length (mm)	265
